Manufacturing of cylinders for the aluminum injection industry
Mould, toolings & die casting
Foundry is an industry where conditions are extreme and difficult with tight spaces and high temperatures. To meet these constraints, HPS relies on its expertise in die casting technology to develop and improve its cylinders.
See our products
Die Casting Cylinders
H160 Co Series
- Modular tie rod.
- Fully configurable, in particular thanks to a multitude of mountings and options.
- Comply with ISO 6020/2 - DIN 24554.
Block Cylinders
VSP Series
- Includes new SL Mounting
- Compact and fast block cylinder.
- It mounts in place of the HVB Series or cylinders complying with the CNOMO standard 05.07.65 to 05.07.70.
- It is the ideal compromise between compact, robustness and speed.
Tie Rod Cylinders
VT-VB Series
- Modular and robust tie rods flanges.
- Fully configurable thanks to a multitude of mountings, feedings and options.
- Working pressure: (VT) 160 bar / (VB) 210 bar
- Bores: Ø32 ... 160 mm
Specific Cylinders
VRE250 Series (Former HPS VRE)
Specific cylinder cooled by water
See our productsSpecific Cylinders
VT-VB Series
- Modular and robust tie rods flanges.
- Fully configurable thanks to a multitude of mountings, feedings and options.
- Working pressure: (VT) 160 bar / (VB) 210 bar
- Bores: Ø32 ... 160 mm
Specific Cylinders
NUG Series
- Pusher cylinder for cutting tools
- The NUG Mounting as before is now NUGP and the new NUGV Mounting has been added with 4 types of fixations. – M2 ; M5 ; M10 ; M11
- HPS International NUG Series cylinders are equipped with 2 or more highly guide rods to increase the capacity of absorbing decentered/transverse efforts and at the same time transmit the necessary force to any point on the front plate. With the new NUGV, all this on one of the most compact cylinders on the market.
Specific Cylinders
VPP Series
Specific cylinder. Short and fixed stroke.
Operating pressure: 250 bar
Bore Ø25 to Ø40 mm
See our productsSpecific Cylinders
Telescopic hydraulic cylinder - New
Double stroke in standard body
See our products
Die Casting Cylinders
NUG Series
- Pusher cylinder for cutting tools
- The NUG Mounting as before is now NUGP and the new NUGV Mounting has been added with 4 types of fixations. – M2 ; M5 ; M10 ; M11
- HPS International NUG Series cylinders are equipped with 2 or more highly guide rods to increase the capacity of absorbing decentered/transverse efforts and at the same time transmit the necessary force to any point on the front plate. With the new NUGV, all this on one of the most compact cylinders on the market.
